Артикул |
D1 |
D2 |
D3 |
L |
ET |
Ход |
Обозначение |
|
50702823 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
230 mm |
30 mm |
Füller 5070.28 ET-230/28/Hub-30/18
|
|
50702833 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
330 mm |
30 mm |
Füller 5070.28 ET-330/28/Hub-30/18
|
|
50702843 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
430 mm |
30 mm |
Füller 5070.28 ET-430/28/Hub-30/18
|
|
50702853 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
530 mm |
30 mm |
Füller 5070.28 ET-530/28/Hub-30/18
|
|
50702863 |
22 - 26 mm |
18 mm |
28 mm |
25 / 40 mm |
630 mm |
30 mm |
Füller 5070.28 ET-630/28/Hub-30/18
|
|
50703223 |
22 - 30 mm |
18 mm |
32 mm |
25 / 40 mm |
230 mm |
30 mm |
Füller 5070.32 ET-230/32/Hub-30/18
|
|
50703233 |
22 - 30 mm |
18 mm |
32 mm |
25 / 40 mm |
330 mm |
30 mm |
Füller 5070.32 ET-330/32/Hub-30/18
|
|
50703243 |
22 - 30 mm |
18 mm |
32 mm |
25 / 40 mm |
430 mm |
30 mm |
Füller 5070.32 ET-430/32/Hub-30/18
|
|
50703253 |
22 - 30 mm |
18 mm |
32 mm |
25 / 40 mm |
530 mm |
30 mm |
Füller 5070.32 ET-530/32/Hub-30/18
|
|
50703263 |
22 - 30 mm |
18 mm |
32 mm |
25 / 40 mm |
630 mm |
30 mm |
Füller 5070.32 ET-630/32/Hub-30/18
|
|
50704023 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
230 mm |
30 mm |
Füller 5070.40 ET-230/40/Hub-30/18
|
|
50704033 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
330 mm |
30 mm |
Füller 5070.40 ET-330/40/Hub-30/18
|
|
50704043 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
430 mm |
30 mm |
Füller 5070.40 ET-430/40/Hub-30/18
|
|
50704053 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
530 mm |
30 mm |
Füller 5070.40 ET-530/40/Hub-30/18
|
|
50704063 |
22 - 36 mm |
18 mm |
40 mm |
25 / 40 mm |
630 mm |
30 mm |
Füller 5070.40 ET-630/40/Hub-30/18
|
|
50704223 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
230 mm |
30 mm |
Füller 5070.42 ET-230/42/Hub-30/18
|
|
50704233 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
330 mm |
30 mm |
Füller 5070.42 ET-330/42/Hub-30/18
|
|
50704243 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
430 mm |
30 mm |
Füller 5070.42 ET-430/42/Hub-30/18
|
|
50704253 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
530 mm |
30 mm |
Füller 5070.42 ET-530/42/Hub-30/18
|
|
50704263 |
22 - 36 mm |
18 mm |
42 mm |
25 / 40 mm |
630 mm |
30 mm |
Füller 5070.42 ET-630/42/Hub-30/18
|
|
50705023 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
230 mm |
30 mm |
Füller 5070.50 ET-230/50/Hub-30/18
|
|
50705033 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
330 mm |
30 mm |
Füller 5070.50 ET-330/50/Hub-30/18
|
|
50705043 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
430 mm |
30 mm |
Füller 5070.50 ET-430/50/Hub-30/18
|
|
50705053 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
530 mm |
30 mm |
Füller 5070.50 ET-530/50/Hub-30/18
|
|
50705063 |
22 - 36 mm |
18 mm |
50 mm |
25 / 40 mm |
630 mm |
30 mm |
Füller 5070.50 ET-630/50/Hub-30/18
|
